Schüco
Schüco is one of Europe’s leading manufacturers of window, door, and glass curtain wall systems, offering a full range of high-end aluminum and vinyl products. Schüco delivers high performance, excellent quality and innovative designs, while maintaining compatibility across their product lines and configurations. This makes Schüco the perfect fit for projects that need both special products and consistent design solutions
Schüco AWS 90.SI+
Additional Information
The Schüco AWS 90.SI+ (Super Insulation) window system perfectly meets structural requirements while offering the greatest possible design freedom – including optimized thermal insulation and passive house certification.
As part of the Schüco AWS modular system for the 90 mm basic depth, the aluminum window offers a high level of flexibility for implementing attractive design solutions in building envelopes. Depending on architectural requirements, it can be configured as a punched opening, ribbon window or insert units in Schüco façades as well as in combination with Schüco door systems. The wide range of opening types includes designs such as side-hung, turn/tilt and tilt/slide vents as well as barrier-free opening and double-vent units. A further benefit for specifiers and architects is the wide range of profiles within the system platform, including corner mullions, structural mullions, symmetrical and asymmetrical mullions, as well as additional combination options, such as with Schüco sun shading and ventilation systems.
The window system with maximum thermal insulation thereby sets standards in terms of planning and design flexibility for the construction of energy-efficient, stylish building envelopes.
- Min. face width – 99 mm
- Uf value of frame (≥) – 0.71 W/(m²·K)
- Max. glass/panel thickness – 68 mm
- Max. vent width – 1700 mm
- Max. vent height – 2500 mm
- Max. sound reduction index Rwp – 47 dB(A)
- Air permeability – Class 4
- Watertightness – Class 9A
- Burglar resistance – Up to RC3
- Wind load resistance – Class C5 / B5
SCHÜCO AWS 75 SI+
Additional Information
In the basic depth of 75 mm, the Schueco Window AWS modular system offers SI designs (Super Insulation) which combine maximum thermal insulation with impressive properties in terms of function, design and fabrication. The standard series – Schueco Window AWS 75.SI+ – features outstanding thermal insulation with a face width of 117 mm. With a continuous center gasket and new glazing rebate insulation, the Schueco SimplySmart technology ensures more efficient fabrication. In combination with the new Schueco AvanTec SimplySmart mechanical generation of fittings, installation can be completed considerably more quickly.
As a block window with a concealed vent frame, Schueco Window AWS 75 BS.SI+ fulfils the highest requirements in terms of architecture thanks to its slim design and maximum transparency.
Schueco AWS 75 WF.SI+ is based on the Schueco block window and is designed specifically for the economical construction of ribbon windows with story-height glazing with a homogeneous mullion/transom appearance.
- Uf values from 0.92 W/(m²K) for aluminium windows with maximum thermal insulation
- Uf value = 1.2 W/(m²K) with 117 mm face width, Uw value = 0.90 W/(m²K) and
- Ug value = 0.6 W/(m²K)
- Centre gasket with fin in microcellular rubber design
- Block window system variant with outstanding thermal insulation
- Min. face width – 91 mmMax. vent width – 1700 mm
- Max. vent height – 2500 mm
- Max. sound reduction index Rwp – 48 dB(A)
- Air permeability – Class 4
- Watertightness – Class 9A
- Burglar resistance – Up to RC3
- Wind load resistance – Class C5 / B5
SCHÜCO AWS 75 PD.SI
Additional Information
Alongside energy efficiency, the seamless integration of form and function is nowadays a fundamental requirement when creating modern building envelopes. With the new Schüco AWS 75 PD.SI Panorama Design window, Schüco now offers an opening unit with minimal internal and external face widths that perfectly meets all of these architectural requirements. System features which are perfectly tailored to one another serve as the basis for this. These include a flush-fitted vent profile appearance on the inside, minimal gasket sightlines, maximum transparency with the narrowest of internal and external face widths, as well as harmonised face widths in the fixed light and opening unit for a uniform frame appearance. Concealed drainage and a clear design with narrow profile radii round off the ground-breaking Schüco AWS 75 PD.SI Panorama Design window system.
- Min. face width – 55 mm
- Uf value of frame (≥) – 1.7 W/(m²·K)
- Max. glass/panel thickness – 50 mm
- Max. vent width – 1450 mm
- Max. vent height – 2500 mm
- Max. sound reduction index Rwp – 46 dB(A)
- Air permeability – Class 4
- Watertightness – Class 9A
- Burglar resistance – Up to RC 2
- Wind load resistance – Class C5 / B5
Schüco ADS 90.SI
Energy efficiency and thermal insulation play an increasingly important role in newbuilds and in the renovation of residential and commercial buildings. With the Schüco ADS 90.SI (Super Insulation) door system, Schüco is setting a low-energy and system standard for aluminum
doors. Expanded insulation zones, a continuous
centre gasket design and special glazing rebate
insulation achieve unbeatable system
properties, such as resistance to driving rain of
up to 750 Pa and Uf
-values of 1.4 W/(m²K). With
appropriate triple glazing or a leafenclosing infill
panel, outstanding Ud-values better <1.4 W/
(m²K) can be achieved.
- Uf value of frame (≥) – 1.4 W/(m²·K)
- Leaf weights up to 160 kg can be supported
- Leaf heights up to 2,500 mm and leaf widths up to 1,400 mm possible
- Area of application – Residential projects, Commercial projects
- Air permeability – Class 4
- Watertightness – to 750 E
- Wind load resistance – Class C4
- Burglar resistance – Up to RC3
SCHÜCO ADS 75 HD.HI
The Schüco ADS 75 HD.HI (Heavy Duty High Insulated) aluminium door system combines high durability with multiple functions and attractive design options – perfect for challenging commercial buildings with high security requirements.
The extremely stable Heavy Duty system is designed specifically for heavy or oversized door leafs with large opening widths and high continuous loads. As a further benefit, the system can also be used as a multifunctional door – including integration in building security and automation systems, e.g. as a panic door in office and public buildings, hospitals or schools.
Together with its narrow face widths, diverse design options and increased burglar resistance and sound reduction, the system makes flexible door solutions possible for the starkly differing requirements of commercial construction.
- System basic depth – 75 mm
- Uf value of frame (≥) – 2.2 W/(m²·K)
- Max. height – 3000 mm
- Max. width – 1400 mm
- Max. glass/panel thickness – 57 mm
- Area of application – Residential projects, Commercial projects
- Surface finishes – RAL, Anodised
- Air permeability – Class 2
- Watertightness – Class 5A
- Wind load resistance – Class C3
- Burglar resistance – Up to RC3
- Impact resistance – Class 1
- Max. vent weight – 200 kg
Schüco AD UP 90.SI
The Schüco AD UP 90.SI door system is the design option with the best thermal insulation. With an identical profile construction and modular foam inserts, the pioneering door system achieves excellent thermal insulation values up to passive house standard.
Together with attractive design options and simple integration of automation components, the system offers maximum design freedom for implementing the most energy-efficient, comfortable and stylish door solutions for luxury residential and commercial construction.
- Uf value of frame (≥) – 1.1 W/(m²·K)
- Max. height – 2500 mm
- Max. width – 1250 mm
- Max. glass/panel thickness – 68 mm
- Max. vent weight – 160 kg
- Area of application – Residential projects, Commercial projects
- Air permeability – Class 4
- Watertightness – Class 5A
- Wind load resistance – Class C2 / B2
- Burglar resistance – Up to RC 2
- Impact resistance – Class 1
SCHÜCO AD UP 75
Excellent insulation properties combined with high stability – the Schüco AD UP 75 door system with a 75 mm basic depth offers high functional reliability for all requirements in luxury residential and commercial buildings.
With its groundbreaking construction principle and modular gasket system, the system sets new standards in thermal insulation, weathertightness, load-bearing capacity and durability for aluminum door systems. With a broad portfolio of fittings and design options, it allows stylish door solutions which meet every requirement for all areas of life and work. The door system is perfect for integration with door communication and access control systems.
- Uf value of frame (≥) – 1.4 W/(m²·K)
- Max. height – 3000 mm
- Max. width – 1400 mm
- Max. glass/panel thickness – 53 mm
- Max. vent weight – 200 kg
- Area of application -Residential projects, Commercial projects
- Surface finishes – RAL, Anodized
- Air permeability – Class 4
- Watertightness – E 750
- Wind load resistance -Class C3 / B3
- Burglar resistance – Up to RC3
- Impact resistance – Class 1
SCHÜCO ASE 80.HI
Barrier-free, very easy to use and a slimline appearance – the high-insulation Schüco ASE 80.HI (High Insulated) sliding and lift-and-slide system offers elegant design solutions for sustainable, user-oriented architecture to passive house level.
The modular and scalable aluminium profile system captivates with the reduced DesignLine interlock section of the vents, which allows the frame units to visually recede into the background.
The level threshold allows the inside and outside areas to transition into one another harmoniously and without barriers.
Concealed fittings components reinforce the puristic and high-quality design, even when open.
A further benefit of the new generation of sliding and lift-and-slide systems is its high flexibility in terms of configuration to suit any user. Options such as the Schüco SmartStop and Schüco SmartClose security and comfort technology ensure the best handling possible.
SCHÜCO ASE 60
The modular and scalable Schüco ASE 60 sliding and lift-and-slide system boasts excellent thermal insulation values, slimline face widths and comprehensive solutions in terms of design and comfort.
A special highlight is that the sliding system can be individually configured in terms of comfort and design. Optional fittings components such as the Schüco SmartStop and Schüco SmartClose security and comfort technology ensure maximum ease of use. A slimline interlock section allows inside and outside to merge together, while the level threshold meets everyday needs for ease of access.
The profile system retains its high-quality design even when open thanks to the concealed fittings components.
The certified burglar resistance of the sliding and lift-and-slide systems ensures increased security requirements are met.
Schüco ASE 67 PD
The thermally insulated Schüco ASE 67 PD (Panorama Design) sliding system allows for flexible solutions that meet the highest demands in terms of ease of use and design; it received the Red Dot Design Award 2019.
The optional level threshold guarantees a seamless transition between inside and outside.
Together with the concealed outer frame integrated in the building structure and the narrow profiles, the versatile sliding systems ensure an architectural design flooded with light which is as transparent as possible.
The pioneering locking mechanism in the interlock section also allows open vent units to be locked.
The puristic design of the Panorama Design sliding system is not only visually eye-catching, but also impresses with its outstanding feel.
- Min. vent height – 2000 mm
- Max. vent height – 3000 mm
- Min. vent width – 1000 mm
- Max. vent width – 3200 mm
- Uw value of window (≥) – 1 W/(m²·K)
- Max. sound reduction index Rwp – 46 dB(A)
- Watertightness – Class 9A
- Burglar resistance – Up to RC 2
SCHÜCO ASS 77 PD.HI
The best possible flexibility: with optimised system components, the highly thermally insulated Schüco ASS 77 PD.HI (Panorama Design High Insulated) sliding system expands the planning and design possibilities of the Schüco Panorama Design portfolio, which is best suited to luxury homes and large projects with high requirements on functionality and comfort.
An opening 90° corner which can be designed with two further moving vents or two fixed fields brings both architectural freedom and user comfort.
A flat outer frame expands the application options for the sliding system, e.g. in renovations.
The optimised foil attachment and the adjustment device guarantee tailored installation solutions in terms of building expansion and attachment to the building structure.
Schüco Seamless is the groundbreaking solution for almost frameless transparency of the building envelope. Seamless stands for the concealed combination of different Panorama Design systems that allows holistic seamless integration concepts to be realised for the building façade. The sliding system is integrated seamlessly in the Schüco FWS 35 PD.HI mullion/transom façade system for an even profile transition with no offset. In this way, the systems achieve a high level of thermal insulation with extremely narrow profile face widths.
- Min. vent height – 1000 mm
- Max. vent height – 3500 mm
- Min. vent width – 1200 mm
- Max. vent width – 3200 mm
- Uw value of window (≥)1 W/(m²·K)
- Max. sound reduction index Rwp – 42 dB(A)
- Watertightness – E 750
- Burglar resistance – Up to RC 2
SCHÜCO ASS 70 FD
The thermally insulated Schüco ASS 70 FD (Folding Door) bi-fold system impresses with narrow face widths and offers a wide range of types with outstanding weathertightness for use in outdoor areas.
The visually appealing system opens up a variety of design options thanks to attractive opening types, such as the 90° corner including a flat, thermally insulated threshold for barrier-free access.
The magnetic retaining catch with an elegant design and matching flat door handle is available as an additional design option.
The flexible and quiet vent stacks can be folded to the right, left, inwards or outwards as required.
SCHÜCO ASS 80 FD.HI
With narrow face widths and a wide range of types which meet all the requirements of current thermal insulation standards, as well as outstanding weathertightness, the highly thermally insulated Schüco ASS 80 FD.HI (Folding Door High Insulated) bi-fold system is ideally suited for use in outdoor areas.
Attractive opening types such as the 90° corner including a flat, thermally insulated threshold for barrier-free access offer a variety of design options for the visually appealing system.
Additionally, the bi-fold system can be designed with a magnetic retaining catch with an elegant design and matching flat door handle.
SCHÜCO FAÇADE SYSTEM FWS 50
The Schüco FWS 50 façade system is an impressive basic system for façades and skylight areas with a high level of flexibility and attractive design options, including optimised fabrication and installation processes. Thanks to a broad system range, solutions for the most varied requirements and applications can be implemented.
A transparent system solution integrated in the profile for spandrel safety barriers blends seamlessly and elegantly into the external façade appearance. The required safety barrier loading for floor-to-ceiling opening units and low spandrel heights can be implemented with consistent profile face widths and a continuous profile.
The mullion/transom façade with 50 mm face widths offers a high degree of design freedom with a large selection of pressure plates and façade cover caps as well as the combination with Schüco window, door and sliding systems.
System-optimised components guarantee the simple and reliable integration of electrical components, e.g. for automated Schüco door or sun shading installations.
With the mullion/transom façade, Schüco is once again fulfilling its obligation to create ecologically sustainable products. The Schüco FWS 50.SI (Super Insulated) system option has been awarded the Silver “Cradle to Cradle Certified™” sustainability label by the independent C2CPII institute in cooperation with EPEA in Hamburg for its recycling properties and minimal toxin content.
- Uf value of frame (≥) – 1.5 W/(m²·K)
- Min. face width – 50 mm
- Max. glass/panel thickness – 62 mm
- Max. weight – 1080 kg
- Surface finishes – Powder, Anodised, Paint
- Air permeability – AE
- Max. sound reduction index Rwp – 48 dB(A)
- Watertightness – RE 1200
- Impact resistance – I5/E5
- Burglar resistance – Up to RC3
- Suitable for safety barrier loading – Yes
- Bullet resistance – Up to FB 4
